Description
The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-29/180 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. Important: High Power RMS reload kits are not compatible with Mid Power RMS products. You will need to set the desired delay time using the 18-38mm Delay Drilling Tool (RDDT), Not Included. The 18-38mm Delay Drilling Tool (RDDT) is available in the AeroTech Accessories section of this website.
This RMS motor reload utilizes RCSs exclusive Black Jack™ aerospace grade composite propellant formulation, which produces a visible black exhaust plume and a denser dark tracking smoke. Black Jack™ motors provide a higher level of thrust than White Lightning™ motors of the same total impulse and are perfect for high lift-off acceleration.
The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators.
Specifications:
Motor Diameter: 1.125 inches (29mm)
Casing Length: 7.25 inches (184mm)
Hardware Required: RMS-29/180
Total Impulse: 135.6 N-sec
Average Thrust: 75.0 newtons
Peak Thrust: 70.3 N-sec
Thrust Duration: 2.4 seconds
Delay Time: adjustable up to 10 seconds
Propellant Weight: 104 grams
Motor Weight: 233 grams
